SSD-A11
High-Gain Circular Polarized Antenna for Enhanced RFID Signal Stability
✔️ Wide 840–960 MHz Frequency Range
Adjustable across 840–960 MHz, supporting UHF RFID deployments in different markets and regional frequency requirements.
✔️ 10.5 dBi+ Gain with Circular Polarization
≥10.5 dBi peak gain and circular polarization help maintain stable tag reading when tag orientation changes, while the 45°/60° beamwidth provides focused coverage.
✔️ Durable ABS+PP Housing
ABS+PP construction provides a practical enclosure for industrial RFID applications, while the SMA-K connector makes integration with compatible RFID readers straightforward.
SSD-A11 is a high-gain uhf rfid antenna designed for fixed RFID systems that require focused and stable tag identification. With adjustable 840–960 MHz operation, ≥10.5 dBi peak gain, circular polarization, and a 45°/60° beamwidth, it can be used with an rfid reader antenna setup in warehouses, logistics areas, retail stores, production lines, access control points, and asset management systems. It is also suitable for system integrators and rfid antenna manufacturers looking for a configurable antenna solution.
SSD-A11 UHF RFID Reader Antenna is built for dense shelf setups in retail or warehouses. With 11dBi gain and an 85° beam, it reads multiple tags up to 3 meters away. Circular polarization reduces orientation issues, and low VSWR keeps reads steady near metal. IP65 rating protects against dust and spills. It works with ISO 18000-6C readers and fits on shelves, walls, or poles without getting in the way.
SSD-A11 supports an adjustable frequency range of 840–960 MHz for different UHF RFID deployment requirements.
Its peak gain is ≥10.5 dBi, providing focused RF coverage for fixed RFID applications.
Yes. Circular polarization helps reduce signal loss caused by tag orientation and polarization mismatch.
The antenna provides a 45°/60° beamwidth for directional RFID coverage.
SSD-A11 has a standard 50Ω characteristic impedance for compatibility with suitable RFID equipment.
It uses an SMA-K connector for connection with compatible RFID readers and RF systems.
The antenna housing is made from ABS+PP, providing a practical enclosure for industrial and commercial installations.
It can be used for warehouse inventory, logistics tracking, retail, production management, access control, and fixed asset identification.
The SSD-A11 covers 840–960 MHz, working across EMEA, FCC, and APAC bands without needing region-specific antennas. Circular polarization handles fast-moving items on conveyors or forklift readers. Lightweight at 850 g, it’s easy to deploy in temporary setups, vehicle-mounted systems, or pop-up centers. Combine it with 4G/WiFi-enabled readers for real-time tracking, rely on IP65 protection outdoors, and use the 70° vertical beam to focus on tagged items in loading docks or shipping containers.
