Let’s be brutally honest. The dream of tapping your iPhone to a warehouse box and reading its RFID tag is, for now, a fantasy. If you need to read RFID with an iPhone for anything beyond a novelty tap, you’re looking at a hardware integration project, not an app download. Your iPhone is a world-class pocket computer with a terribly limited built-in RFID radio. Here’s what actually works and what you’ll need to buy.
Your iPhone has NFC (Near Field Communication), a subset of RFID that works at 13.56 MHz (HF). Its capabilities are locked down by Apple for security and a consistent user experience.
What it can do (with an app like “NFC Tools”):
What it absolutely cannot do:
If your goal involves UHF or LF tags, stop trying to make the built-in NFC work. Your solution is external.
For professional use, the iPhone acts as the intelligent interface, while a dedicated, external RFID reader does the heavy lifting. They connect via Bluetooth Low Energy (BLE).
Step 1: Buy the Right Hardware
You need an iOS-compatible UHF RFID reader. Look for a device like the CYKEO Mobile series—a handheld, Bluetooth reader explicitly designed to pair with iPhones and iPads. This reader contains the specialized radio and antenna your iPhone lacks.
Step 2: The Developer’s Path (SDK Integration)
If you’re building an enterprise app (e.g., for inventory, asset tracking), here’s the real workflow:
Cykeo RFID IoT Solution Products R&D Manufacturer
Info.plist:
NSBluetoothAlwaysUsageDescriptionNFCReaderUsageDescription (even if just for background context)swift
import CykeoMobileSDK
class ScannerVC: UIViewController, CYReaderDelegate {
var reader: CYUHFReader?
override func viewDidLoad() {
super.viewDidLoad()
// Initialize and set delegate
reader = CYUHFReader.shared
reader?.delegate = self
}
@IBAction func connectTapped(_ sender: UIButton) {
// Connect to a previously paired reader's identifier
reader?.connect(to: storedPeripheralUUID)
}
@IBAction func startScanTapped(_ sender: UIButton) {
// Start continuous inventory
reader?.startInventory()
}
// MARK: - CYReaderDelegate Methods
func didDiscoverTag(_ epc: String, rssi: Int) {
// This is called on a background thread.
DispatchQueue.main.async {
// Update your UI, add to a local Realm or Core Data store
self.logTextView.text.append("\(epc)\n")
}
}
func connectionStateDidChange(to state: CYConnectionState) {
// Update UI for connecting/connected/disconnected
}
}
setPower(30), setSession(.s1), setQValue(5). These settings dramatically affect read range and speed in your specific environment.Info.plist privacy descriptions. This is the #1 cause of early failure.For one-off tasks, check if your reader manufacturer offers a generic scanning app on the App Store (CYKEO and others often do). It lets you test hardware and perform basic scans. For any integrated business process—where scanned data must instantly sync with your database or ERP—you must build a custom app.
The essential takeaway for how to read RFID with an iPhone is this: The iPhone is not an RFID reader. It is a superb mobile computer that can command an RFID reader. Your project’s success depends 90% on selecting the right external reader and faithfully integrating its SDK. Start by purchasing the reader, pairing it with the manufacturer’s own app, and confirming it reads your tags. Only then should you open Xcode. The hardware is the gatekeeper; the software is just the key.
