CK-TP5C

RFID Gate Opener

Industrial-Grade Access Control for High-Traffic Logistics Hubs

✔️ Customizable EAS & Face Recognition

✔️ 200+ Tags/Sec Adaptive RSSI Filtering

✔️ 4-Antenna Array with Millimeter-Level Accuracy

Talk to an Expert

Email Our Team

PRECISION ACCESS, ZERO LAG

The CK-TP5C RFID Gate Opener delivers industrial-grade access control for logistics hubs and secure facilities. Featuring ISO 18000-6C compliance, 4-antenna spatial sensing, and adaptive RSSI filtering, it achieves 200+ tags/sec scanning with millimeter-level tracking accuracy. Customizable EAS alarms and dual OS support (Windows/Android) ensure seamless integration into high-security gate opener systems.

Ideal for vehicle access gates in distribution centers, personnel checkpoints in secure facilities, and automated entry systems for tool rooms or archival vaults.

Parts management

Production line material

Clothing Management

Hotel linen management

Electricity meter Control and Management

Factory Automation

CykeoCK-TP5C RFID Gate Opener Specification

Download

Online Procurement

KEY FEATURES OF CYKEO CK-TP5C RFID GATE OPENER

4-Antenna Full Coverage

Quad-polarized antennas eliminate dead zones in 2270mm×1040mm gate area

200 Tags/Sec High Speed

EPC C1G2 protocol with dynamic power adjustment 1-33dBm

Dual Alarm Modes

Real-time light & sound alerts for online/offline EAS security

Windows/Android OS

10.1″ touchscreen with Windows 10 or Android 7.1 for flexible HMI

Extreme Environment Ready

Operates at -20°C~60°C and 10%~90% humidity

Multi-Protocol Support

Seamless integration with WMS, ERP, and legacy systems

Expandable Connectivity

RJ45 + optional WiFi/4G for IIoT deployments

Rugged Construction

Aircraft-grade aluminum frame with anti-corrosion coating

Cykeo CK-TP5C RFID Gate Opener Specifications

Main Specifications

BrandCykeo
ModelCK-TP5C
Product NameRFID Gate Opener

Physical Parameters

MaterialAluminum profile outer frame, sheet metal +PMMA
Dimensions2270mm×1040mm×1200mm
Screen10.1″ capacitive touchscreen
SystemWindows/Android
Core controlI5-4,8G, 128GBSSD Windows 10 RK3399, 4G+32G, android 7.1，
Trigger modeInfrared trigger
Weight50KG

Developer Support

API InterfacesRESTful & Native APIs (IoT/ERP Integration Ready)
Secondary Development SDKFull toolkit for custom firmware & app development
LanguagesJava, C# (Cross-Platform Compatibility)

* Product performance is based on testing in a controlled environment. Depending on the environment, your results may vary.

Performance Parameters

Frequency Range840MHz~960MHz
Air Interface ProtocolEPC C1G2, ISO 18000-6c
Antenna modeCircular polarization
Antenna power0-33db
Read distance0-30cm
Capacity≥200 tags/batch
ConnectivityRJ45*1、USB*2、WIFI
Reading and writing functionSupports multi-label recognition, label data filtering, and RSSI perceptible signal strength
Scan Time3-5 sec
standby power＜100w
PowerAC 220V

Operating Environment

InputAC 220V ±10% 50/60Hz
Humidity≤90%
Operating Temp-20℃~60℃
Humidity Range10%~90% RH (non-condensing)
IP RatingIP54 (dust/water resistant)

NEED A CUSTOM SOLUTION?

Submit your requirements and valid contact details – Our engineers will deliver a custom solution within 24 hours.

RFID GATE OPENER FAQS

How Does the CK-TP5C Handle Dense Vehicle Traffic at Logistics Gates?

Answer:
The CK-TP5C RFID gate opener uses 4-antenna spatial coordination and dynamic RSSI thresholds to manage high-density vehicle flows. When trucks trigger infrared sensors:

Frequency hopping (840-960MHz) avoids interference from engine ignition systems.
EPC C1G2 batch processing scans 200+ pallet tags/sec while filtering non-vehicle items.
Adaptive Q algorithms prioritize tags within 2-5m range, reducing misreads by 89%.
Case Study: A German logistics hub processed 500+ trucks/day with 99.2% tag accuracy after installing CK-TP5C gates.

Can This Gate Opener Integrate with Facial Recognition for Personnel Access?

Infrared-capable cameras that work in low-light conditions.
Android SDK to sync facial data with RFID tags for dual authentication.
Real-time alerts sent to security teams when unregistered persons attempt access.
Tip: Combine with EAS alarms to trigger door locks during unauthorized entries.

How Does the System Operate During Power Outages?

Answer:
The CK-TP5C supports fail-safe operation through:

Optional solar panels providing 72hr backup power.
Offline EAS alarm mode storing 100,000+ access records locally.
4G auto-failover maintaining cloud connectivity when WiFi drops.
Performance Data: Achieved 98% uptime during grid failures in Brazilian warehouses.
