The CK-DP13D employs a multi-layered technical approach to ensure reading precision and avoid interference from stray tags, which is critical in dense asset environments.

• 1. Precision-Tuned RF Field Design:The workstation’s antenna is engineered to create a highly controlled and localized electromagnetic field. Instead of a wide, diffuse pattern, the RF energy is concentrated primarily upwards to a height of 100cm, with very limited lateral spread (≤10cm). This spatial confinement acts as a “virtual scan tunnel,” ensuring that only items intentionally placed within this defined volume are activated and read, while ignoring assets on nearby shelves or carts.
• 2. Adaptive Power Control & Frequency Hopping:The reader module intelligently adjusts its transmission power based on the real-time environment. For single-item check-outs, the power can be set to a lower level to minimize the field’s footprint. Additionally, the device hops across the 840-960 MHz frequency band to counteract RF noise and multipath interference, which further enhances the stability and accuracy of the read zone, preventing sporadic reads from outside the target area.
• 3. Software-Based Filtering & Session Management:The accompanying software utilizes advanced anti-collision algorithms and session controls. Operators can initiate a scan session that is logically isolated, and the system can be configured to ignore tags that were not presented during the current transaction. This provides a digital layer of verification on top of the physical RF containment, double-checking that the captured data corresponds precisely to the assets physically present on the scan area.

Yes, the CK-DP13D is built as a platform for customization, not just a fixed-function terminal. Its flexibility is rooted in both its hardware configurability and comprehensive software development support.

• 1. Role-Based Access Control via Integrated Authentication:The standard High-Frequency (HF) card reader allows for granular user permissions. Through the SDK, developers can create a system where different user roles (e.g., Operator, Supervisor, Administrator) have tailored interfaces and capabilities. For example, a standard user might only see a basic check-out list, while a supervisor’s login could unlock functions for asset registration, user management, and audit report generation.
• 2. Conditional Workflow Triggers and Data Validation:The system can be programmed to enforce business rules. Custom workflows can include mandatory fields (e.g., “reason for withdrawal,” “project code”), conditional approvals (e.g., pop-up alert requiring a supervisor’s badge scan for high-value items), and data validation (e.g., checking if an asset is due for maintenance before allowing it to be checked out). This ensures compliance with specific operational procedures.
• 3. Multi-Modal Data Capture and Association:By leveraging the optional barcode scanner or ID card reader, the system can enrich asset records. For instance, an asset can be registered by scanning its RFID tag, and then associated documentation can be linked by scanning a barcode on its manual. This creates a comprehensive digital twin of the physical asset within the management system, far beyond simple identification.

The CK-DP13D is designed as a smart edge device that seamlessly feeds data into broader enterprise IT ecosystems, offering multiple robust pathways for integration.

• 1. Standardized API Interfaces for Real-Time Sync:The device provides a comprehensive Software Development Kit (SDK) that includes RESTful API libraries. This allows the workstation to push transaction data (user ID, asset EPCs, timestamp, action type) directly to a central asset management server or middleware in real-time using standard HTTP/HTTPS protocols. This ensures that your central database (e.g., SAP, Oracle) is updated the moment an action is completed at the workstation, providing live inventory visibility.
• 2. Flexible Connectivity and Batch Processing Options:With standard Gigabit Ethernet and optional Wi-Fi/4G, the workstation can connect to the network in the way that best suits your infrastructure. For environments with intermittent connectivity, the SDK also supports local data caching. Transactions are stored securely on the device’s SSD and can be synchronized in batches once a stable connection is re-established, ensuring no data loss.
• 3. Configurable Data Export and Database Middleware:For simpler integrations, the system can be configured to export structured data files (e.g., CSV, XML) to a designated network share at scheduled intervals. Furthermore, the SDK includes sample code for direct connectivity to common databases like MySQL, SQL Server, and Oracle, allowing the application to execute stored procedures or perform direct inserts/updates, offering maximum flexibility for IT departments to implement a tailored integration strategy.
